Introduction
Taking full advantage of significant advances in digital speaker measuring techniques such as Klippell™ symmetry and non-linear distortion analysis, laser scanning interferometry, acoustic CAD simulation and our own cutting edge acoustic technologies, Tannoy engineers have developed the Precision D active monitors.
Main Features
The new Precision D Active range incorporates the latest Tannoy Dual Concentric™ driver and WideBand™ Technology to deliver near field monitoring speaker designs that set new standards of acoustic performance and accuracy.
These models provide superior bandwidth, significantly low levels of distortion, very smooth response, extremely accurate phase control, high sensitivity levels and input source flexibility. Add in a comprehensive calibrated EQ facility for mid / near / close field working in full / half /quarter and eighth space environments, mid-band and high frequency trim shelving controls, a choice of power and cabinet sizes, analogue and digital input trim facilities, and user requirements can be satisfied for all listening environments and applications.
Specifications
| Precision 8D |
| PERFORMANCE |
| Frequency response (1) |
44Hz-51kHZ |
| Max SPL(2) |
119dB |
| Distortion |
<0.4% |
| DRIVE UNIT |
| Dispersion |
(@-6dB) 90 Degrees |
| Dual Concentric™ LF/MID |
200mm (8”) Dual ConcentricTM constant directivity driver with multi fibre paper pulp cone |
| Dual Concentric™ HF |
25mm (1”) titanium dome, neodymium magnet system |
| SuperTweeter™ |
25mm (1”) titanium dome, neodymium magnet system |
| Shielded |
Yes |
| ELECTRONIC SYSTEM |
| Inputs |
Balanced XLR/Jack, SPDIF Phono |
| SPDIF sampling rate |
44.1 - 96kHz |
| Sensitivity |
775mV for 120W |
| Crossover frequency |
2.2kHz |
| Amplifier output power |
LF - 120W, HF - 60W, ST - passive feed from HF |
| User Controls |
Front panel mounted on/standby/mute LED indicator, Rear trim +4/-10dB, 80Hz hi-pass switch (for AV use), 16way DIP switch selection for optimum response (see chart) |
| Outputs |
SPDIF RCA |
| Power Supply |
Fixed mains voltage - region specific (to order) 110/220/230v |
| CABINET |
| Type |
Optimised bass-reflex loaded |
| Construction |
MDF cabinet, front baffle T&G front and back |
| Finish |
Black cabinet, Grey painted baffle with brushed aluminium insert |
| Cabinet dimensions (HxWxD) |
440mm x 272mm x 370.5mm (17 3/8” x 10 3/4” x 14 5/8”) |
| Total Cabinet weight |
18kg (39.6lbs) |
| Activ-Assist |
Activ-Assist PC/MAC based software-measuring system to assist with the setting of the DIP switches to reach a substantially linear and flat response at the monitoring position. |
| (1) +/- 3 dB , measured at 1m in an anechoic chamber. (2) Peak SPL at mix position for 1 pair driven |
